PEEK Pipe




  • PEEK Tubing 1/16" x 0.13mm
  • PEEK Tubing 1/16" x 0.13mm
  • PEEK Tubing 1/16" x 0.13mm
  • PEEK Tubing 1/16" x 0.13mm

PEEK Tubing 1/16" x 0.13mm

1/16 Inch PEEK Tubing Material

In the world of fluid handling and precision engineering, the choice of tubing can make all the difference. When you demand exceptional performance, reliability, and versatility, look no further than our 1/16 inch PEEK tubing. Engineered with precision and crafted from high-quality materials, this tubing is the perfect solution for a wide range of applications, from laboratory experiments to industrial processes.

PEEK Tubing Material Datasheet


MATERIAL GRADE

Key Features:

Chemical Resistance: Our 1/16" PEEK tubing easy bending is renowned for its outstanding resistance to a variety of chemicals, acids, and solvents. This means that it can be safely used in environments where other materials might corrode or degrade.


Heat Tolerance: With a high continuous-use temperature range, this tubing maintains its structural integrity even under extreme heat conditions. It can handle the rigors of demanding processes with ease.


Precision and Consistency: When it comes to precise fluid handling, our PEEK tubing stands out. Its uniform dimensions and smooth inner surface ensure reliable flow rates and consistent performance.


Versatility: Whether you're working in a laboratory, manufacturing facility, or research institution, our 1/16 inch PEEK tubing is a versatile choice. It can be used for applications such as chromatography, microfluidics, and analytical instruments.


Durability: PEEK (Polyether Ether Ketone) is known for its exceptional mechanical strength and wear resistance. This tubing is built to last, reducing the need for frequent replacements and maintenance.


Precision Machined: Our tubing is precision machined to meet the highest quality standards. It's designed for easy installation and compatibility with various fittings and connectors.


Applications:

Laboratory Research: Researchers rely on our PEEK tubing for its purity and compatibility with a wide range of chemicals, making it ideal for chromatography, sample analysis, and more.


Industrial Processes: In industrial settings, where durability and chemical resistance are paramount, our tubing excels. It's used in chemical processing, manufacturing, and other critical applications.


Microfluidics: Engineers and scientists working on microfluidic systems appreciate the precision and consistent flow characteristics of our PEEK tubing, ensuring accurate results.


Analytical Instruments: When accuracy is crucial, such as in analytical instruments like HPLC systems, our tubing plays a vital role in maintaining the integrity of your results.


Invest in the superior performance of 1.6mm PEEK tube and elevate your fluid handling processes to new heights. Whether you're conducting experiments, manufacturing products, or running analytical tests, our tubing ensures that your fluids are handled with precision, reliability, and the utmost care. Trust in our commitment to quality and innovation, and experience the difference that PEEK soft coiled tubing can make in your applications.


ARKPEEK-1000: 100%PEEK

Produced from virgin polyetheretherketone resin and offers the highest toughness and impact resistance of all types.

ARKPEEK-CF30: 30% Carbon Fiber + 70% PEEK

Carbon fiber reinforcement lends the material a high level of rigidity and creep strength, high mechanical strength and heat conductivity values.

ARKPEEK-GF30: 30% Glass Fiber + 70% PEEK

Glass filled PEEK exhibits increased mechanical strength and high rigidity. improved creep strength and dimensional stability are achieved by this glass filled PEEK. These properties make this material suitable for use in parts which are exposed to high static loads over long periods in high temperature conditions.

ARKPEEK-MOD: 10% Carbon Fiber + 10% PTFE +10%  Graphite

high performance engineering plastic with product characteristics including excellent sliding and abrasion & wear resistance, high mechanical strength and high dimensional stability. The long term service temperature range of PEEK Rod is from -30°C to 250°C and has a short term maximum service temperature of 310°C.


Size Table

Product specifications
NameODID
PEEK Capillary1(±0.05)0.45(±0.05)
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.13
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.25
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.50
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ0.75
1/16"PEEK CapillaryΦ1.5-Φ1.60Φ1.25
PEEK CapillaryΦ1.7-Φ1.8Φ0.66-Φ0.8
PEEK CapillaryΦ2.5Φ1.5
PEEK CapillaryΦ2.5Φ1.9
PEEK CapillaryΦ2.45Φ2.1
1/8"PEEK CapillaryΦ3.10-Φ3.22Φ1.00
1/8"PEEK CapillaryΦ3.10-Φ3.22Φ1.60
PEEK CapillaryΦ4Φ3.4
PEEK CapillaryΦ4.5Φ2.5
PEEK CapillaryΦ20.5Φ16.5
PEEK CapillaryΦ12Φ11
PEEK CapillaryΦ11Φ7.5
PEEK CapillaryΦ6Φ4
PEEK CapillaryΦ19.8Φ16.5
